Lifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre Table

Product Name: Multi-functional Hospital Surgical Operation Theatre Table SEO Description: We are a factory specialized in producing high-quality hospital surgical operation theatre tables with lifting, head-foot tilting, left-right tilting, and up and down corner folding features.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
DST-1A
Manufacture Company
Yes
Electric or Hydraulic
Both Electric Hydraulic
Transport Package
Wooden Case
Specification
GW: 340KG, 1.7CBM
Trademark
YUDA
Origin
China
Production Capacity
100 Sets Per Month

Product Description

German technology Hospital Operation Room Equipment Stainless Steel Multifunctional Hydraulic Operation Table Sugical Bed
Precision micro-motor Multifunctional Hospital OT Electric Operating Surgical Surgery Bed Table
Made by GRAND MEDICAL GROUP, the largest medical manufacturer in North China, we produced an amazing DST-III Electric Hydraulic Heavy Load Operating Surgery table .


DST-500 Electric Comprehensive Operating Table

The DST-500 electric operating table has the advantages of beautiful appearance, light weight, labor-saving, convenient operation, safe and reliable use, and stable operation. The table top lifting, tilting, tilting forward and backward, and locking are realized by a dedicated motor and operated by buttons. The accessories can be disassembled and are easy to use.

Advantages and characteristics
Using precision micro-motor, the product has superior rigidity, uniform and stable running speed, accurate positioning, reliable performance and durability.
Lifting, head-foot tilting, left-right tilting, up and down corner folding of the panel back and other actions are driven by an independent power system.
Mattress: made of integral sponge with high sealing degree and soft texture. Natural shaping, with memory recovery function, reducing local pressure. Seamless, waterproof, easy to clean, anti-static, detachable.
The bed frame of the operating table is made of high-quality nickel-chromium stainless alloy steel. It can be used for more than 15 years without rusting.
The bed column shell and base are sprayed with stainless steel to prevent glare, reduce eye fatigue of medical staff, and facilitate cleaning and disinfection.

Lifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre Table Lifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre Table Lifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre Table Lifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre Table

The main technical parameters:
Item Parameters
Table size 2040, 520;
2040 mm in total length, 520 mm in width;
Table height 850,1100;
minimum 850 mm, maximum 1100 mm;
Head board ≥40º , ≥90º,;Fold up ≥40º, fold down ≥90º, detachable;
Back board ≥75º , ≥25º;Fold up≥75º, Fold down≥25º
Table ≥20º , ≥20º;
Forward tilt ≥ 20º, backward tilt ≥ 20º;
Table ≥19º , ≥19 º;Left tilt≥19º, right tilt≥19º;
The leg plate bifurcated type ≥90 º,≥90 º,.
External fold ≥90 º, downward fold ≥90 º, detachable.
External lumbar bridge stroke ≥120mm
Lifting stroke ≥250
Power supply voltage 220V±22v   50HZ±1H
Safety classification: IClass I
Waterproof rating IPX4
Work system Continuous operation with short load
Working limit: 10%,2/2010%, 2 minutes/20 minutes
Safe load: 200kg
Weight: 210kg

Lifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre TableLifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre TableLifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre TableLifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre TableLifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre TableLifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre TableLifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre TableLifting, Head-Foot Tilting, Left-Right Tilting, up and Down Corner Folding Hospital Surgical Operation Theatre Table
